PowerCat 6A Shielded Pre-Terminated Cable Assemblies

'

Part No: PCPT6ASXXXXX

Region: emea apac

Molex PowerCat 6A Shielded Pre-Term cable assemblies are ideal for use in data centres and high speed network environments. The PowerCat 6A pre-terminated shielded assemblies are designed to support secure-high speed 10GBASE-T and is backward compatible with 10/100/1000BASE-T networks. These cable assemblies are made from high quality Cat 6A U/FTP 4-pair shielded 23AWG solid copper wire and are pre-terminated to robust die cast zinc DataGate C6A shielded shuttered jack which provide superior alien crosstalk (AXT) suppression, and provides enhanced electromagnetic interference (EMI) protection. These pre-term cable assemblies are available as jack-to-jack, plug-to-jack, or plug-to-plug. The six individual cables are bundled together with spiral wrapping placed every metre.

Features & Benefits Technical Info
  • Factory terminated and tested
  • Up to 80% faster to install than traditional field installation
  • Cat 6A U/FTP 4-pair individually shielded 23 AWG solid copper cable pre-terminated with DataGate RJ45 shielded shuttered jacks at each end
  • Fully compliant with ISO/IEC 11801 Amd.1 and Amd.2 Ed. 2.0 Class EA
  • LS0H sheath
  • 10G performance when installed as a complete PowerCat 6A shielded system
  • Field AXT testing not required because cables are compliant by design
  • RoHS compliant
  • Pre-terminated PowerCat 6A DataGate shielded jacks snap into DataGate unloaded patch panels
  • Cable bundles with pulling eye available upon request

Mechanical Characteristics
Cable
Conductor size: 23 AWG solid copper wire
Screen material: Aluminum/polyester shield with tinned copper drain wire
Nominal O.D. (1 cable): 7.0 mm
Nominal O.D. (6 cables): 22 mm
Sheath: Low Smoke Zero Halogen (LS0H)
Bend radius: 8X O.D. minimum
Operating temperature range: -20°C to 60°C

Connectors
Operating life: 750 insertion cycles
Housing: Zinc alloy plated bright Ni/Cu
Contact material: Copper Alloy
Contact plating: 1.2700μm Au/1.2700μm Ni minimum
Contact force: 100g minimum
Plug retention force: 6.8kg minimum RJ45 receptacle and plug dimensions compliant with IEC 60603-7 and FCC 47 Part 68

Electrical/Optical Characteristics
Max voltage: 150 VAC (max)
Max current: 1.5A @ 25°C

Commercial Standards
ISO/IEC 11801 2nd Ed Amd 1 & Amd 2 Class EA
TIA-568-C.2 Cat 6A

Fire Propagation Tests
LS0H: IEC 60332-1 IEC 61034-2

Note: For full part  number breakdown and details, please see product datasheet
